Germany OBO surge arresters_DS-N、DS-BNC、S-UHF、LP7/16

Product No：Pro2009416213832
Product Model：DS-N、DS-BNC、S-UHF、LP7/16
UpdateTime：
Views：1180

Details：


The DS coaxial protection devices are suitable for discharging high pulsed currents and are used as basic protection of lightning protection zones 0 to 2. Due to the low insertion damping and a low-capacity structure, the protection elements are suitable for very high transmission frequencies.
These protection devices are used in coaxial systems (wave resistance 50 Ω, 75 Ω) and are available with various connectors and sockets.



Coaxial data line protection devices.
• Basic protection
• High impulse current carrying capacity x 2.5 kA (10/350)
• Simple installation (adapter plug), m = male / w = female connector
• Various plug combinations
• With UHF connector
• Optimal transmission performance





Coaxial data line protection devices.
• Basic protection
• High impulse current carrying capacity x 2.5 kA (10/350)
• Simple installation (adapter plug), m = male / w = female connector
• Various plug combinations
• With BNC connector
• Optimal transmission performance





Coaxial data line protection devices for basic protection
• High impulse current carrying capacity 2 x 2.5 kA (10/350)
• Simple installation (adapter plug), m = male / w = female connector
• Optimal transmission performance
• 5 years warranty
• With V connector
