Germany OBO surge arresters_MSR protection for power supply VF 230-AC-FS、VF 230-AC

Product No：Pro200941620445
Product Model：VF 230-AC-FS、VF 230-AC
UpdateTime：2010.06.02
Views：2715



VF ...-AC/DC: Surge protection device, fine protection Type 3 to EN 61643-11 (Class D to DIN
VDE 0675, Part 6-11) for distributor installation.
Suitable for DC and AC voltage systems
With visual function display
With installation-friendly, screwless connection clamps
In a space-saving 17.5 mm grid
Y connection
Application: universal use on 35 mm top-hat rails in any standard distributor housing.





VF 230-AC/DC...: Surge protection device, fine protection Type 3 (Class C) to DIN VDE 0675, Part
6-11 for distributor installation with remote signalling.
With remote signalling for function monitoring (potential-free changeover contact)
Suitable for DC and AC voltage systems
With visual function display
With installation-friendly, screwless connection clamps
In a space-saving 17.5 mm grid
Y connection
Application: universal use on 35 mm top-hat rails in any standard distributor housing.



Details：


 VF230-AC-FS.pdf
