Germany OBO surge arresters_Surge arrester / surge controller V 20-C、V 20-C/+NPE

Product No：Pro2009416162139
Product Model：V 20-C、V 20-C/+NPE
UpdateTime：2010.06.03
Views：3079

The SurgeController Type V 20-C is a surge arrester Type 2 (Class 2) according to DIN VDE 0675 Part 6-11 (DIN EN 61643-11) designed for overvoltage protection to DIN VDE 0100 part 443. For protecting low voltage consumer systems from transient overvoltage due to atmospheric discharges and switching actions.
The V 20-C/3+NPE combination is universally suitable for the TN-C-S, TN-S TT power supply systems. The total discharge gap between N and PE prevents voltage drags on the conductor, thereby preventing impermissible, high contact voltages.
The SurgeController is used in almost all areas of industrial and residential buildings. It can be installed in every commercially available distributor housing.



Upper and lower part pre-mounted and ready for connection.
V 20-C/...: Surge protection device Type 2 Class C) to VDE 0675 part 6-11 (DIN EN 61643-11).
With new MultiBase base part and Multi-connection clamps
Complete unit consisting of upper part and base, pre-mounted and ready for connection
VDE-tested
Suitable for TN network systems
Plug-in upper part; upper part can be separated from base without tools
Including thermal and dynamic separating device
With visual display of defects
High current conductivity and long service life
Marked connections
Application example: residential buildings, single-family homes






V 20-C/...: Surge protection device Type 2 Class C) to VDE 0675 part 6-11 (DIN EN 61643-11).
With new MultiBase base part and Multi-connection clamps
Complete unit consisting of upper part and base, pre-mounted and ready for connection
VDE-tested
Suitable for TN- and TT network systems
Plug-in upper part; upper part can be separated from base without tools
Including thermal and dynamic separating device
With visual display of defects
High current conductivity and long service life
Marked connections
Application example: residential buildings, single-family homes without outer lightning protection
system.



Details：


 V 20-C、V 20-C/+NPE
