Germany OBO surge arresters_Lightning current and surge arrester / CombiController V 25-B+C、V 25-B+C/+NPE

Product No：Pro200941616759
Product Model：V 25-B+C、V 25-B+C/+NPE
UpdateTime：2010.06.03
Views：2289

The V 25-B+C CombiController is a combined lightning and surge arrester, Type 1+2 (Class B+C) to DIN EN 61643-11. It provides lightning protection equalisation with the energy supply lines, while also protecting against overvoltages from the power supply.
The V 25-B+C/3+NPE combination is universally suitable for the TN and TT power supply systems. The total discharge gap between N and PE prevents voltage drags on the conductor, thereby preventing impermissible, high contact voltages.
The CombiController is used as a combined lightning and surge arrester in residential buildings. The protector is also used in buildings accommodating additional lines.
Other variants with FS, AS, FS-Sü and housing are described on the following pages.



V 25-B+C/...: Combination arrester set, lightning and surge arrester Type 1+2 to DIN EN 61643-11
(B+C to VDE 0675 part 6)
With new MultiBase base part and Multi-connection clamps
Complete unit consisting of upper part and base, pre-mounted and ready for connection
Plug-in arrester with dynamic separating device
With visual function display
Voltage protection level < 0,9 kV
Enclosed, non-extinguishing zinc varistor arrester for use in normal commercial distributor
housings
Marked connections
Application example: building with an overhead power line supply or lightning protection system,
for building up lightning protection equipotential bonding.





V 25-B+C/...: Combination arrester set, lightning and surge arrester Type 1+2 to DIN EN 61643-11
(B+C to VDE 0675 part 6)
With new MultiBase base part and Multi-connection clamps
Complete unit consisting of upper part and base, pre-mounted and ready for connection
Suitable for any TN and TT network systems
Plug-in arrester with dynamic separating device
With visual function display
Voltage protection level < 1,5 kV
Enclosed, non-extinguishing zinc varistor arrester for use in normal commercial distributor
housings
Marked connections
Application example: building with an overhead power line supply or lightning protection system,
for building up lightning protection equipotential bonding.



Details：


 V25-B+C.pdf
